HLKP provides H/W based encryption and decryption solution DORCA semiconductor is a security chip embedded with RSA, ECC256,ECDSA, ECDH, SHA256 and AES256 algorithms.
The ultra-small HSM (Hardware Security Module), which can be adapted to a variety of IoT devices, provides excellent efficiency and price advantages to prevent malicious eavesdropping at the source. The SSL/TLS protocol can be perfectly implemented in the data interaction between the device and the server.
| Part NO. | Package Type | Feature | Interface | Operation Voltage | Application | Datasheet |
|---|---|---|---|---|---|---|
| DORCA-2 |  |
1 ：Data Security 2 ：Secured Data storage 3 ：Any data storage with encryption 4 ：Crypto Engine(AES128) 5 ：Secured communications |
SPI | 3.3V/1.8V | Cellular phone / Webcam /IPWalkietalkie / VolP / Video calldevice / loT / Several Contents& S/W |  |
| DORCA usD-2 |  |
1 ：Support secure communication between individual or in group 2 ：Applied with AES128 Encryption 1 Decryption 3 ：32 bits OTP cells for user serial 4 ：16GB data storage |
SD | 1.8V | -VolP Cellular phone. -Linux OS. Windows OS(USB to Card leader). etc |
|
| DORCA-3 |  |
1 ：32-bit ARM Cortex-M0 Core 2 ：AES-128/256. SHA-256. 3 ：ECC256, ECIES, ECDSA. RSA2048,64KB eFlash, 64KB SRAM.128 bit TRNG. HW_ JD. PUF/Random 3 ：SPI. 100 MHZ system clock, POR, Soft Reset 4 ：Key Management: OKA3. Revision ControlMIDR, Chip Disable Mode |
SPI | 3.3V | -loT product security. loT Module security -DRM. CAS, STB. ContentsProtection, -IP Camera, Door Lock, GasValve. Eletric Water Gas Meter -USIM. VISA Card, Kakao BankSecurity. Digital Wallet. -Digital ldentification Card,Passport -Password Manager. CloudStorage Security. VPN. PTT. Wolkie-talkie, -AI Speaker Security |
|
