We mainly produce Integrated inductors,Magnetic glue inductors, CD wound inductors,High-frequency stacked inductors, Magnetic beads, Ring inductors, l-shaped inductors,Common mode inductors and Act.
The products are widely used in Communication,Servers, High-tech electronics, Ships, Computers,Data transmission, audio video processing,and automotive electronic systems.
We can replace these brands completely: TDK,Murata, Sumida, Wurth, Panasonic, Sunlord and etc.
Our production capacity is 40KK per month.
| Part No. | Series | Inductance (μH) | Size code | Marking | Datasheet |
|---|---|---|---|---|---|
| HLTYH0402-4.7uH/M | HL0402 | 4.7±20% | 4.6±0.25mm/4.1±0.35mm/2.0mm Max(LxWxH) |  |
|
| HLTYH0402-3.3uH/M | HL0402 | 3.3±20% | 4.6±0.25mm/4.1±0.35mm/2.0mm Max(LxWxH) | |
|
| HLTYH0402-2.2uH/M | HL0402 | 2.2±20% | 4.6±0.25mm/4.1±0.35mm/2.0mm Max(LxWxH) | |
|
| HLTYH0402-1.5uH/M | HL0402 | 1.5±20% | 4.6±0.25mm/4.1±0.35mm/2.0mm Max(LxWxH) | |
|
| HLTYH0402-1uH/M | HL0402 | 1±20% | 4.6±0.25mm/4.1±0.35mm/2.0mm Max(LxWxH) | |
|
| HLTYH0402-0.68uH/M | HL0402 | 0.68±20% | 4.6±0.25mm/4.1±0.35mm/2.0mm Max(LxWxH) | |
|
| HLTYH0402-0.56uH/M | HL0402 | 0.56±20% | 4.6±0.25mm/4.1±0.35mm/2.0mm Max(LxWxH) | |
|
| HLTYH0402-0.47uH/M | HL0402 | 0.47±20% | 4.6±0.25mm/4.1±0.35mm/2.0mm Max(LxWxH) | |
|
| HLTYH0402-0.33uH/M | HL0402 | 0.33±20% | 4.6±0.25mm/4.1±0.35mm/2.0mm Max(LxWxH) | |
|
| HLTYH0402-0.22uH/M | HL0402 | 0.22±20% | 4.6±0.25mm/4.1±0.35mm/2.0mm Max(LxWxH) | |
|
| HLTYH0402-0.1uH/M | HL0402 | 0.1±20% | 4.6±0.25mm/4.1±0.35mm/2.0mm Max(LxWxH) | |
|
| HLTYH04012P-6.8uH/M | HL04012 | 6.8±20% | 4.4±0.35mm/4.2±0.25mm/1.2mm Max(LxWxH) | |
|
| HLTYH04012P-4.7uH/M | HL04012 | 4.7±20% | 4.4±0.35mm/4.2±0.25mm/1.2mm Max(LxWxH) | |
|
| HLTYH04012P-2.2uH/M | HL04012 | 2.2±20% | 4.4±0.35mm/4.2±0.25mm/1.2mm Max(LxWxH) | |
|
| HLTYH04012P-1.5uH/M | HL04012 | 1.5±20% | 4.4±0.35mm/4.2±0.25mm/1.2mm Max(LxWxH) | |
|
| HLTYH04012P-1uH/M | HL04012 | 1±20% | 4.4±0.35mm/4.2±0.25mm/1.2mm Max(LxWxH) | |
|
| HLTYH04012P-0.68uH/M | HL04012 | 0.68±20% | 4.4±0.35mm/4.2±0.25mm/1.2mm Max(LxWxH) | |
|
| HLTYH04012P-0.47uH/M | HL04012 | 0.47±20% | 4.4±0.35mm/4.2±0.25mm/1.2mm Max(LxWxH) | |
|
| HLTYH04012P-0.33uH/M | HL04012 | 0.33±20% | 4.4±0.35mm/4.2±0.25mm/1.2mm Max(LxWxH) | |
|
| HLTYH04012P-0.22uH/M | HL04012 | 0.22±20% | 4.4±0.35mm/4.2±0.25mm/1.2mm Max(LxWxH) | |
